Blue Diamond MINI EXCAVATOR BRUSH CUTTER – HEAVY DUTY

Name: Blue Diamond MINI EXCAVATOR BRUSH CUTTER – HEAVY DUTY
Brand: Blue Diamond
Availability: OutOfStock

Videos

Call for Price

Get a Quote Get Financed Value a Trade Contact Us Book a Demo Get Directions Get Directions Print

Overview

Blue Diamond® Mini Excavator Brush Cutters are engineered for 6,000 to 15,000 lb mini excavators and offer 36", 42" and 50" cutting widths. The greaseable direct drive system has a 3/4" thick blade carrier that stores energy and keeps the blades cutting even in difficult conditions. These brush cutters use a 3-blade system with straight AR400 double edged blades offering a 4" cutting capacity.

Specifications

Model

MINI EXCAVATOR BRUSH CUTTER – HEAVY DUTY

Category Name

Attachments

Year

2026

Sale Type

New

Manufacturer

Blue Diamond

features & benefits

80cc, 100cc, 125cc and 160cc hydraulic motor options
Greaseable direct drive system
4" cutting diameter
Bidirectional operation
3 - AR400 double-sided blades
1/4″ thick deck for 50″
3/16″ thick deck for 36″ and 42″
Optional chain guards and deflectors available for 36″ and 42″ models
50" model has standard chain guard
No case drain required

APPLICATIONS:

Mowing steep banks
Mowing around ponds
Cutting back brush on roadways and trails
Reaching over fences and guardrails

technical data

Part Number	Model	Weight (No Mount)	Host Machine Size	Flow Range (GPM)	Chain Curtain
103600	36" W/ 80CC	551 lbs	fits 6,000-15,000 lbs	13-28	Optional
103610	36" W/ 100CC	544 lbs	fits 6,000-15,000 lbs	29-36	Optional
103650	42" W/ 80CC	630 lbs	fits 7,300-19,000 lbs	13-24	Optional
103660	42" W/ 100CC	662 lbs	fits 7,300-19,000 lbs	25-31	Optional
103709	50" W/ 80CC	939 lbs	fits 12,000-19,000 lbs	13-22	Yes
103712	50" W/ 100CC	934 lbs	fits 12,000-19,000 lbs	23-28	Yes
103713	50" W/ 125CC	941 lbs	fits 12,000-19,000 lbs	28-33	Yes
103714	50" W/ 160CC	965 lbs	fits 12,000-19,000 lbs	34-41	Yes
203662-KIT Optional Chain Guard Kit	36"	60 lbs
203665-KIT Optional Chain Guard Kit	42"	80 lbs
