Blue Diamond PALLET FORKS - BLOCK & BRICK - HEAVY AND STANDARD DUTY

Name: Blue Diamond PALLET FORKS - BLOCK & BRICK - HEAVY AND STANDARD DUTY
Brand: Blue Diamond
Availability: OutOfStock

Call for Price

Get a Quote Get Financed Value a Trade Contact Us Book a Demo Get Directions Get Directions Print

Overview

The Blue Diamond® Heavy and Standard Duty Block & Brick Pallet Forks are available to fit a wide range of equipment, including skid steers, tractors, and telehandlers that have the skid steer quick attach. Block and Brick tines are available in 42" and 48" lengths and designed to help construction and landscaping crews move large amounts of masonry materials quickly and efficiently.

Specifications

Model

PALLET FORKS - BLOCK & BRICK - HEAVY AND STANDARD DUTY

Category Name

Attachments

Year

2026

Sale Type

New

Manufacturer

Blue Diamond

features & benefits

Tines fit any Class 2 fork frame
3,200 – 4,800 lbs capacity

technical data

Part Number	Model	Tine Size	Lift Capacity	Weight
314500	Pallet Fork, STD, W/Steps	48” x 2” x 1 1/2”	3,200 lbs	313 lbs
314505	Pallet Fork, STD, W/Steps	48” x 2” x 2”	4,000 lbs	445 lbs
314515	Pallet Fork, STD, W/Steps	48” x 2” x 1 1/2”	3,200 lbs	363 lbs
314520	Pallet Fork, HD, W/Steps/D-Ring	48” x 2” x 2”	4,800 lbs	410 lbs
314510	Pallet Fork, STD, W/Steps	48” x 2” x 2”	4,800 lbs	471 lbs
114175	42" Block/Brick Tines STD Class 2	42" x 2" x 1 1/2"	3,200 lbs	64 lbs
114178	48" Block/Brick Tines STD Class 2	48" x 2" x 1 1/2"	3,200 lbs	69 lbs
114185	42" Block/Brick Tines STD Class 2	42" x 2" x 2"	4,800 lbs	77 lbs
114180	48" Block/Brick Tines STD Class 2	48" x 2" x 2"	4,800 lbs	84 lbs
	114 series part numbers are tine only.
	314 series are assemblies with 4 tines included.
