MULCHER - PERFECT PLUS - NB MACHINERY

Mulcher with a wide mouth intake designed for very heavy work with pruning residues of up to 12-15 cm in olive groves, vineyards, fruit orchards, citrus, grass, etc.

STANDARD EQUIPMENT

– Hydraulic displacement with a zinc-coated solid bar CAT II.
– Free wheel in the gearbox.
– Reinforced back roller of 170 mm of diameter with scraper integrated in rear door.
– Skids.
– Double row of counter hammers (one jagged profile and one row of special triple-crest, bolted-on, U-shaped Niubo counter knife).
– Rear door with holes, with hydraulic opening by two cylinders and back roller integrated in the same.
– Reinforced iron protective bands.
– Very reinforced hammer rotor and bearings.

Note: all models are supplied with series hammers; except when specified with blades in the order.

MODELS

MOD.	MM	KG	Nº	Nº	C.V.	R.P.M	Nº	MM	MM	MM
TPP150	1500	690	16	32+16	70-90	540	4	1700	1050	1400
TPP160	1600	770	16	32+16	80-90	540	4	1800	1050	1400
TPP180	1800	850	20	40+20	80-90	540	5	2000	1050	1400
TPP200	2000	930	22	44+22	80-100	540	5	2200	1050	1400
TPP220	2200	1015	22	44+22	85-110	540	5	2400	1050	1400
